Colfax CX21460g-XH2 2U Rackmount Server




  • NVIDIA MGX™ Modular Server Design
  • 1x Intel® Xeon® 6700/6500 Series Processor
  • 4x NVIDIA GPUs
  • 16x DDR5 DIMM Sockets
  • 2x 2.5" Gen5 NVMe Drive Bays

Features

  • NVIDIA MGX™ Modular Server Design
  • 1x Intel® Xeon® 6700/6500 (Model Specs) Series Processor
  • 4x NVIDIA GPUs (NVIDIA H200 NVL / RTX PRO 6000 Blackwell Server Edition PCIe GPUs)
  • 16x DIMM Sockets Support DDR5 ECC RDIMM
  • 4x FHFL PCIe 5.0 x16 Slots for GPUs
  • 2x FHFL PCIe 5.0 x16 Slots for NICs
  • 1x FHFL PCIe 5.0 x16 Slot for DPU
  • 2x 2.5" Gen5 NVMe Drive Bays
  • 2x M.2 Slots with PCIe Gen5 x4 Interface
  • 2x 10Gb/s LAN Ports via Intel® X550-AT2
  • 1x Dedicated Management Port
  • 4x 2000 Watts RPSU, 80 PLUS Titanium
  • Dual ROM Architecture Supported




Technical Specifications

Enclosure • 2U
• Dimension (W x H x D) 17.24" x 3.4" x 35.43" (438 x 87 x 900 mm)
CPU • Socket E2 (1x LGA 4710)
• Single Intel® Xeon® 6700/6500 Series Processor
• Supports CPU TDP up to 350W
Memory • 16x DIMM sockets
• DDR5 memory supported only
• 8-channel memory architecture
• RDIMM: Up to 6400 MT/s
• MRDIMM: Up to 8000 MT/s
Expansion Slots • 4x PCIe 5.0 x16 FHFL slots for GPUs
• 2x PCIe 5.0 x16 FHFL slots for NICs
• 1x PCIe 5.0 x16 FHFL slot for DPU

Note: The system supports 4x NVIDIA H200 NVL PCIe GPUs at 25°C ambient, arranged as two 2-GPU sets, each with a 2-way NVLink bridge
Storage Front
• 2x 2.5" hot-swap Gen5 NVMe drive bays
Internal
• 2x M.2 (2242/2260/2280/22110), PCIe Gen5 x4
Networking • 2x 10Gb/s LAN ports (1x Intel® X550-AT2)
• 1x 10/100/1000 Mbps management LAN
Video • Integrated in ASPEED AST2600 controller
- 1 x Mini-DP
Power Supply • 4x 2000W redundant PSUs
• AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-220V~/ 10A, 50-60Hz
- 220-240V~/ 10A, 50-60Hz
• DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12.2Vsb/ 3A
- Max 1800W/ 200-220V~
+12.2V/ 148A
+12.2Vsb/ 3A
- Max 2000W/ 220-240V~ or 240Vdc Input
+12.2V/ 164A
+12.2Vsb/ 3A
• 80 PLUS Titanium
System Fans • 2x 60x60x56mm (24,000/23,200rpm)
• 4x 80x80x80mm (17,500/15,000rpm)
Front I/O I/O board - CFPX142:
• 2x USB 3.2 Gen1 ports (Type-A)
• 1x Mini-DP
• 2x RJ45 ports
• 1x MLAN port
• 1x Power button with LED
• 1x ID button with LED
• 1x Reset button
• 1x Storage activity LED
• 1x System status LED
Rear I/O • N/A
Backplane I/O • Speed and bandwidth: PCIe Gen5 x4
TPM • 1x TPM header with SPI interface
• Optional TPM2.0 kit
Server Management • Onboard Chipset - Aspeed AST2600
• GIGABYTE Management Console web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings


Block Diagram
