Powerful Visual Computing Platforms with NVIDIA Quadro


Colfax Workstations





2-Socket Intel® Xeon® Scalable Processor based Workstations

ModelCPUGPUMemoryStorageExpansion Slots
ProEdge™ SXT9800Dual Intel® Xeon® Scalable ProcessorsUp to 5

NVIDIA® Tesla® T4/V100/P40

12 DIMMs4 Hot-Swap SATA HDDs / SSDs

1 M.2 NVMe SSD		5 Double Width PCIe 3.0 x16

1 Single Width PCIe 3.0 x16
ProEdge™ SXT9700Dual Intel® Xeon® Scalable ProcessorsUp to 4

NVIDIA® Tesla® T4/V100/P40

16 DIMMs8 Hot-Swap SATA HDDs / SSDs

1 M.2 NVMe SSD		4 Double Width PCIe 3.0 x16

2 Single Width PCIe 3.0 x16
ProEdge™ SX7200Dual Intel® Xeon® Scalable ProcessorsNVIDIA Quadro® / Quadro RTX16 DIMMs8 Hot-Swap SATA HDDs / SSDs (Optional 2 NVMe SSDs)

1 M.2 NVMe SSD		6 PCIe (4 PCIe 3.0 x16)
ProEdge™ SX6800Dual Intel® Xeon® Scalable ProcessorsNVIDIA Quadro® / Quadro RTX12 DIMMs8 Hot-Swap SATA HDDs / SSDs

1 M.2 NVMe SSD		6 PCIe (5 Double Width PCIe 3.0 x16)
ProEdge™ SX6400Dual Intel® Xeon® ScalableNVIDIA Quadro® / Quadro RTX12 DIMMs4 Hot-Swap 3.5" SATA HDDs

4 2.5" SATA or 4 U.2 NVMe SSDs

1 M.2 NVMe SSD		7 PCIe (4 PCIe 3.0 x16)
ProEdge™ SX6300Dual Intel® Xeon® ScalableNVIDIA Quadro® / Quadro RTX16 DIMMs4 Fixed 3.5" SATA HDDs

2 U.2 NVMe SSDs

1 M.2 NVMe SSD		6 PCIe (4 PCIe 3.0 x16)


1-Socket Intel® Xeon® Scalable, Intel® Xeon® W, Intel® Xeon® E, Intel® Core™ X-Series Processor based Workstations

ModelCPUGPUMemoryStorageExpansion Slots
ProEdge™ Z500Single 10th Gen Intel® Core™NVIDIA Quadro RTX™4 DIMMs2 Fixed 3.5" HDDs/SSDs

2 M.2 NVMe SSDs		2 PCIe 3.0 x16
ProViz™ IX500 Small Form Factor WorkstationSingle 10th Gen Intel® Core™Integrated Intel® Graphics (DisplayPort 1.4, HDMI 2.0a) + Discrete Graphics Card Support (NVIDIA Quadro RTX™)2 DIMMs1 SATA HDD

2 2.5" SSDs

2 M.2 NVMe SSDs		1 PCIe 3.0 x16 (Supports GPU up to 330mm)
ProEdge™ SX3900Single Intel® Xeon® Scalable or Intel® Xeon® W-32xxUp to 4

NVIDIA Quadro RTX™		12 DIMMs8 Hot-Swap SATA HDDs / SSDs

4 M.2 NVMe SSD		4 PCIe 3.0 x16
ProEdge™ SX3800Single Intel® Xeon® ScalableUp to 2

NVIDIA Quadro® / Quadro RTX™		12 DIMMs8 Hot-Swap SATA HDDs / SSDs

4 M.2 NVMe SSD		4 PCIe 3.0 x16
ProEdge™ SX2400Single Intel® Xeon® W 2xxx SeriesNVIDIA Quadro® / Quadro RTX™8 DIMMs4 Fixed SATA HDDs / SSDs

2 U.2 NVMe SSDs

1 M.2 NVMe SSD		3 PCIe 3.0 x16
ProEdge™ DX935Single Intel® Xeon® W 2xxx SeriesNVIDIA Quadro RTX™8 DIMMs2 Fixed SATA HDDs

2 U.2 NVMe SSDs

2 M.2 NVMe SSDs		7 PCIe 3.0 x16
ProEdge™ DX930Single Intel® Xeon® W 2xxx SeriesNVIDIA Quadro RTX™8 DIMMs2 Fixed SATA HDDs

2 SSDs

1 M.2 NVMe SSD		2 PCIe 3.0 x16

2 x PCIe 3.0 x16 (Single at x16, dual at x8/x8)
Intel® NUC 9 Pro NUC9VXQNXSingle Intel® Xeon® E-2286MIntegrated Intel® UHD Graphics P630 (2x Thunderbolt 3, HDMI 2.0a)

+ Discrete Graphics Card Support		2 DIMMs2 M.2 NVMe SSDs2x M.2 PCIe 3.0 x4 Slots (PCH)

1x M.2 PCIe 3.0 x4 Slot (CPU)

Double-wide PCIe 3.0 x16 (CPU) Slot shared with PCIe x4 (CPU) Slot
ProEdge™ DX950Single Intel® Core™ X-SeriesNVIDIA Quadro RTX™8 DIMMs2 Fixed SATA HDDs

3 U.2 NVMe SSDs

2 M.2 NVMe SSDs		7 PCIe 3.0 x16
ProEdge™ DX925Single Intel® Core™ X-SeriesNVIDIA Quadro RTX™8 DIMMs2 Fixed SATA HDDs

2 SSDs

1 U.2 NVMe SSD

2 M.2 NVMe SSDs		7 PCIe 3.0 x16
ProEdge™ DX920Single Intel® Core™ X-SeriesNVIDIA Quadro RTX™8 DIMMs2 Fixed SATA HDDs

2 SSDs

1 M.2 NVMe SSD		7 PCIe 3.0 x16
ProEdge™ DX830Single Intel® Core™ X-SeriesNVIDIA Quadro RTX™8 DIMMs2 Fixed SATA HDDs

2 SSDs

1 M.2 NVMe SSD		3 PCIe 3.0 x16
ProEdge™ SX2200Single Intel® Xeon® EIntegrated HDMI 2.0a, DVI-D, DisplayPort 1.2 Port4 DIMMs4 Fixed SATA HDDs / SSDs

2 M.2 NVMe SSDs

1 U.2 NVMe SSD (shared with M.2)		2 PCIe 3.0 x16
ProEdge™ SX1400Single Intel® Core™ i9 X-series / Extreme EditionNVIDIA Quadro® / Quadro RTX™8 DIMMs4 Fixed SATA HDDs / SSDs

2 U.2 NVMe SSDs

2 M.2 NVMe SSDs		4 PCIe 3.0 x16


1-Socket AMD Ryzen™ Processor based Workstations

ModelCPUGPUMemoryStorageExpansion Slots
ProEdge™ TRX33003rd Gen AMD Ryzen™ Threadripper™

AMD TRX40 Chipset		NVIDIA Quadro RTX™8 DIMMs2 Fixed SATA HDDs

2 M.2 NVMe SSDs		3 PCIe 4.0 x16
ProEdge™ AX930AMD Ryzen™ 5000 Series

AMD X570 Chipset		NVIDIA Quadro RTX™4 DIMMs2 Fixed SATA HDDs

2 U.2 NVMe SSDs

2 M.2 NVMe SSDs		2 PCIe 4.0 x16
ProEdge™ AX910AMD Ryzen™ 5000 Series

AMD B550 Chipset		NVIDIA Quadro RTX™4 DIMMs2 Fixed SATA HDDs

2 U.2 NVMe SSDs

2 M.2 NVMe SSDs		1 PCIe 4.0 x16
ProViz™ AX500 Small Form Factor WorkstationAMD Ryzen™ 5000 Series

AMD X570 Chipset		NVIDIA Quadro RTX™2 DIMMs1 SATA HDD

2 2.5" SSDs

1 M.2 NVMe SSD		1 PCIe 4.0 x16 (Supports GPU up to 330mm)
